Overview:

Mini PCB 5mm Width COB Flexible led strips, 400led/m, RA80, 3000K/4000K/6000K, DC12V/DC24V, 8w/m, mini 5mm width white PCB, 2-Pin ordinary or waterproof connect wire output; high color efficiency, uniform illumination, can be bent freely, not easy to be broke and not affect the current.

The Key feature is the cut length, 10mm/Cut for the 12V version, and 2cm/cut for the 24V version, good for some special applications.

Data sheet:

Product:	Mini PCB 5mm Width 400led/m COB Flexible led strips
Item No.:	ADY-COB-400-05DC12
LED:	COB LED, 400LEDs/m, RA80, 2700K, 3000K, 4000K, 6000K
View angle:	180°
IC Chip:	N/A
Input voltage:	12V
Power:	8w/m
Size:	5000x5x2(mm)

Features

1) High brightness, low light decay. lifespan>50,000 hours, 2-year warranty;
2) Pure color, CCT avaliable 2000-7000k. DC12V/24V, safe & low power consumption;
3) No light dot or spot; soft light, Arbitrarily bending, smaller bendable angle;
4) 180° view angle;
5) Easy to connect & install Free cuttable soft FPC; 10mm/Cut of the 12V verstion, and 20mm/Cut of the 24V verstion.
6) Dustproof and water resistant IP65; Flexible ribbon for curving around bends;
7) Solid-state, high shock vibration resistant;
8) very good heat dissipation, better than the SMD2110/2216/2835 led strips.

Wiring Diagram & Size:

Application:

1) Architectural decoration Lighting; Backing lighting for signage letters;
2) Decoration lighting for under water project; Archway /Canopy & Bridge Edge Lighting;
3) Auditorium walkway lighting, Amusement park / Theater lighting;
4) Stairway Accent Lighitng, Channel letters lighting;
5) Furniture Decoration Lighting; Cove Lighting etc;

 Order info: (Color: White or R/G/B/Y)

SN	Model Number	LED	PCB Width	Voltage	Power	Waterproof
1	ADY-COB-400-05DC12	400led/m	5mm	DC 12V	5-14w/m	IP20/IP65/IP67
2	ADY-COB-400-05DC24	400led/m	5mm	DC24V	4-12w/m	IP20/IP65/IP67
3	ADY-COB-320-0824	320led/m	8mm	24V	4-12w/m	IP20/IP65/IP67
4	ADY-COB-528-0524	528led/m	5mm	24V	8w/m	IP20/IP65/IP67

Photos

What is COB LED chips onboard – COB LED Lighting?

COB (Chips on Board), is a new technology of LED packaging for the LED light engines. Multi LED chips are packaged together as one lighting module. When it lights up, it looks like a lighting panel.

LED(light-emitting diode) is a new technology with the advantage of saving energy and a very long lifespan. But all LED light source can not be faultless especially SMD, HP, flux LED, etc. Compare to traditional lighting such as a fluorescent lamp, as it is super bright in a small size, it cause uncomfortable glare. In the case of no diffused optical lens used, such LEDs usually cause glare and zebra stripes. But when an optical lens or cover used, it will cause light loss when the LED beam passes through this lens or cover.

---

Why COB?

> LED is super bright in a small size, it causes uncomfortable glare. In the case of no diffused optical lens used, such LEDs usually cause glare and zebra stripes.
> COB won’t cause uncomfortable glare.
> No light dot or spot; soft light, Arbitrarily bending, smaller bendable angle;
> Very good heat dissipation.
