H803TC Cloud Master Controller

**LED Online / Offline Cloud Master Controller H803TC | Support Madrix**

Features and Description:

(1) H803TC can work with PC(online), SD card(offline) or DMX console.
(2) H803TC drives maximum 170000 pixels, 2 ports control maximum 255 slave controllers.
(3) Slave controllers include H802RA and H801RC.
(4) By combining H803TC with H802RA, you can set address for DMX512 chips.
(5) H803TC transmits signal based on Ethernet Protocol.
(6) Use four buttons or PC to switch files, set play mode, speed and brightness.
(7) SD card supports FAT32, FAT16 format, maximum capacity is 64G bytes, stores up to 64 DAT files.

Data sheet:

Product:	LED Online / Offline Cloud Master Controller H803TC \| Support Madrix
Model No.:	H803TC
Controllable:	Can drive 170000 Pixels with 2 networt ports (85000Pixels/port), 255 slave controllers;
Input Volage:	AC100-240V
Consumption:	3W
Net weight:	1.1kg/pcs
Dimension:	270 x 150 x 43(mm)
Supported driver chips:	Almost all of the digial led chips, including single SPI, Double SPI, DMX512, and more
